- Mag Drive Rotary Vane Pump Mag 2- 301J035F126D1A
Mag Drive Rotary Vane Pump Mag 2- 301J035F126D1A
Product Type: Other Industries
* GPH rating at 1725RPM/60Hz and LPH rating at 1450RPM/50Hz
¹ Consult with a PROCON representative for high temperature applications over 194°F (90°C)
² Mechanical Horsepower requirement based on pump tested with water at room temperature and maximum operating pressure 250psi (17.5BAR)
35GPH
100LPH
30psi
Mag 2
Brass
G 3/8"
-4°F
250°F
100cP
2400RPM
PROCON
Special Clearance for High Temperature Applications
3.3ft
6pH
84138100
C8 Outer/C8 Inner
250psi
60dB(a)
100psi
0.29hp (216W)
5000ppm
1000RPM
Pump
301J035F126D1A
MAG Rotary Vane Pump
M2
4.69lb (2.13Kg)
30 to 59psi (2 to 4 BAR)
Clockwise
Piece
Bypass- Ultem
External adjust
Znode Multifront
6.6ft
- Details
- Features
- Applications
- Documents
Flow Rate GPH
35GPH
Flow Rate LPH
100LPH
System Pressure (max)
30psi
Series
Mag 2
Material
Brass
Standard Ports
G 3/8"
Min Fluid Temperature
-4°F
Max Fluid Temperature
250°F
Max Fluid Viscocity
100cP
Max Speed
2400RPM
Brand
PROCON
Internal Component Clearance High Temp Applications
Special Clearance for High Temperature Applications
Dry Suction Lift
3.3ft
Fluid Acidity
6pH
HSS Commodity Code
84138100
Magnet Material
C8 Outer/C8 Inner
Max Discharge Pressure
250psi
Max Sound Level
60dB(a)
Max Static Pressure PSI
100psi
Max Mechanical Power Requirement
0.29hp (216W)
Maximum Total Dissolved Solids (TDS)
5000ppm
Min Speed
1000RPM
Product Classification
Pump
Product Code
301J035F126D1A
Product Family
MAG Rotary Vane Pump
Product Family Sub Group
M2
Product Weight
4.69lb (2.13Kg)
Relief Valve Set Pressure Range
30 to 59psi (2 to 4 BAR)
Rotation
Clockwise
UOM
Piece
Valve Type
Bypass- Ultem
Valve Configuration
External adjust
Vendor
Znode Multifront
Wet Suction Lift
6.6ft
* GPH rating at 1725RPM/60Hz and LPH rating at 1450RPM/50Hz
¹ Consult with a PROCON representative for high temperature applications over 194°F (90°C)
² Mechanical Horsepower requirement based on pump tested with water at room temperature and maximum operating pressure 250psi (17.5BAR)
