- Mag Drive Rotary Vane Pump Mag 207- 317H035F11QB1C
Mag Drive Rotary Vane Pump Mag 207- 317H035F11QB1C
Product Type: Other Industries
* GPH rating at 1725RPM/60Hz and LPH rating at 1450RPM/50Hz
¹ Mechanical Horsepower requirement based on pump tested with water at room temperature and maximum operating pressure 250psi (17.5BAR)
35GPH
100LPH
100psi
Mag 207
Stainless Steel
NSF STD. 169 Listed
G 3/8"
-4°F
160°F
100cP
2400RPM
PROCON
3.3ft
2pH
84138100
Carbon
C16 Outer/NEO Inner
250psi
60dB(a)
100psi
0.29hp (216W)
1000RPM
Pump
317H035F11QB1C
MAG Rotary Vane Pump
M8
2.4lb (1.09Kg)
100 to 150psi (7 to 10 BAR)
Clockwise
Piece
Solid- Ultem
Balanced- External adjust
Znode Multifront
6.6ft
- Details
- Features
- Applications
- Documents
Flow Rate GPH
35GPH
Flow Rate LPH
100LPH
System Pressure (max)
100psi
Series
Mag 207
Material
Stainless Steel
Agency Approvals
NSF STD. 169 Listed
Standard Ports
G 3/8"
Min Fluid Temperature
-4°F
Max Fluid Temperature
160°F
Max Fluid Viscocity
100cP
Max Speed
2400RPM
Brand
PROCON
Dry Suction Lift
3.3ft
Fluid Acidity
2pH
HSS Commodity Code
84138100
Internal Component Material
Carbon
Magnet Material
C16 Outer/NEO Inner
Max Discharge Pressure
250psi
Max Sound Level
60dB(a)
Max Static Pressure PSI
100psi
Max Mechanical Power Requirement
0.29hp (216W)
Min Speed
1000RPM
Product Classification
Pump
Product Code
317H035F11QB1C
Product Family
MAG Rotary Vane Pump
Product Family Sub Group
M8
Product Weight
2.4lb (1.09Kg)
Relief Valve Set Pressure Range
100 to 150psi (7 to 10 BAR)
Rotation
Clockwise
UOM
Piece
Valve Type
Solid- Ultem
Valve Configuration
Balanced- External adjust
Vendor
Znode Multifront
Wet Suction Lift
6.6ft
* GPH rating at 1725RPM/60Hz and LPH rating at 1450RPM/50Hz
¹ Mechanical Horsepower requirement based on pump tested with water at room temperature and maximum operating pressure 250psi (17.5BAR)
